Professional Lab pH ORP Temperature Data Logger

  • Widely used in laboratory, research & development, environmental studies.
  • During the pH mode, Up to 5 points push-button calibration with auto-buffer recognition.
  • Expanded memory stores and recalls up to 500 readings.
  • Selectable pH buffer standards and temperature units.
  • Automatically calculates and displays electrode slope after calibration.
  • Automatic Temperature Compensation (ATC) ensures highly accurate measurements over the entire range.
  • Calibration due reminder prompts you to calibrate the meter regularly.
  • During ORP mode, Single point offset calibration allows user adjusts displayed value to a known standard.
  • Absolute or Relative millivolt (R.mV) measurement provides accurate ORP readings.
  • Automatic endpoint function freezes the stable measured values for easy reading and recording data.
  • Manual temperature calibration provides accurate temperature value.
  • Help message as a operational guide to helps you understand how to use meter.
  • Setup menu lets user customizes buffer standards, calibration points, stability conditions, resolution, temperature units, date and time to meet measurement requirements.
  • Reset function to allow all settings back to factory default values.
  • Built-in real-time clock stamps stored data to meets GLP standards.
  • Stored data can be transferred into computer via USB communication
pHMeasurement range-2.000 – 20.000 pH
Accuracy± 0.002 pH
ResolutionSelectable 1 to 3 digits after decimal
TemperatureMeasurement range0 ~ 105°C (32 ~ 212 °F)
Accuracy± 0.5°C
ORPMeasurement range-1999.9 to 1999.9 mV
Accuracy± 0.2mV
ResolutionSelectable 1 to 2 digits after decimal
Temperature compensationAutomatic or Manual (0 ~ 100°C)
Temperature unitCelsius / Fahrenheit
Temperature calibrationManual
DisplayDual LCD display for simultaneous pH & temperature readouts (130 x 110mm)
pH CalibrationsUp to 5 points
Calibration due reminder0 to 30 days
Data recording500 sets with date & time stampings
Data outputVia USB communication interface
Stability conditionsSelectable High / Low
ConnectionBNC connector for pH
Case materialABS plastic
Data holdManual or automatic
Power supplyDC 5V or AC power adapter
Power offAutomatic or Manual (10, 20 or 30 minutes after inactivity)
Reset functionYes
Dimensions (LxWxH)210 x 188 x 60 mm
  • 1 x Benchtop pH & Temperature Meter
  • 1 x pH Electrode
  • 1 x 250ml pH4 Buffer Powder
  • 1 x 250ml pH7 Buffer Powder
  • 1 x 250ml pH10 Buffer Powder
  • 1 x Electrode Storage Solution Powder
  • 1 x 5V Power Supply
  • 1 x Instruction Manual
  • 1 x Standard Factory Packing
