5 Channels Wireless Weather Station Data Logger

  • Outdoor temperature range: -40 to 60 °C
  • Resolution: 0.1°C
  • Accuracy: ±1°C
  • Indoor / Outdoor humidity range: 10 to 99%
  • Accuracy: ±5% (testing condition: 20 to 90% under 0-45°C)
  • Transmission range: Up to 100m line of sight (open area condition)
  • Dip switch selectable remote channels
  • Min / Max Memory for temperature & humidity
  • Frequency: 868 MHz
  • Update Rate: 60 sec
  • Alarm duration: 120 sec
  • Console Dimensions (L x H x W): 11.5 x 8.2 x 4 cm
  • Sensor Dimensions (L x H x W): 12 x 4.2 x 1.8 cm



Power requirements:

  • Console Power Consumption: 5V / 200 mA
  • Console AC Adapter: 5V / 1A
  • Remote Sensors: 2 x 1.5V AA batteries
  • 5 channels indoor or outdoor thermo-hygrometer monitor with data logging function
  • Measurements of Air Temperature, Humidity, Dew point & Heat Index
  • Graphical real time data display for all measurements
  • Minimum and maximum temperature and humidity display with easy reset option
  • Data extraction through micro SD card to PC
  • Auto Re-sync if sensor reception is interrupted
  • Full colour TFT display
  • Programmable alarm
  • Temperature & humidity calibration function
  • Product in compliance with Part 15 of the FCC rules
  • 1 x Main Display Console
  • 5 x Thermo-hygrometer Remote Transmitters
  • 1 x USB Cable
  • 1 x PC software
  • 1 x 16G Micro SD Memory Card
  • 1 x AC Power Adapter (AU type)
  • 1 x User Manual
  • 1 x Standard Factory Packing
